  • MATRIX MAXI

    MAXI

    Perfect model for large inventory levels

    • Capacity: 3,000-5,000 items
    • TOUCH cabinet is supplied with PC and monitor
    Drawers per cabinet 1-12 (depends on drawer heights and quantity of Auto-Locks)
    Drawer heights
    • 50mm
    • 75mm
    • 100mm
    • and 125mm
    Load weight per drawer Up to 50 kg (90 kg for Jumbo drawer)
    Cabinet weight 400-600 kg (varies depending on number of drawers and Auto-Locks)
    Cabinet dimensions 1180 mm(W) x 752 mm(D) x 1469 mm(H),
    46"(W) x 30"(D) x 58"(H)
    Electrical supply 100 V - 230 V
  • MATRIX MINI

    MINI

    Perfect model for small to medium inventory levels

    • Capacity: 1,000-2,000 items
    • Smaller in size and less drawer capacity than MAXI
    • TOUCH cabinet is supplied with PC and monitor
    Drawers per cabinet 1-5 (depends on drawer heights and quantity of Auto-Locks)
    Drawer heights
    • 50mm
    • 75mm
    • and 100mm
    Load weight per drawer 20kg
    Cabinet weight 165 kg (varies depending on number of drawers and Auto-Locks)
    Cabinet dimensions 860 mm(W) x 581 mm(D) x 800 mm(H),
    34"(W) x 23"(D) x 32"(W)
    Electrical supply 100 V - 230 V
  • MATRIX MAXI Premium

    MAXI Premium

    Large touch screen monitor for easy operation

    • QR code reader, fingerprint reader, high-spec PC (i5)
    • Your company logos can be printed on the sides of the cabinet upon request
    • 2-year warranty
    Drawers per cabinet 1-12 (depends on drawer heights and quantity of Auto-Locks)
    Drawer heights
    • 50mm
    • 75mm
    • 100mm
    • 125mm
    Load weight per drawer Up to 50 kg (90 kg for Jumbo drawer)
    Cabinet weight 400-600 kg (varies depending on number of drawers and Auto-Locks)
    Cabinet dimensions 1180 mm(W) x 752 mm(D) x 1469 mm(H),
    46"(W) x 30"(D) x 58"(H)
    Electrical supply 100 V - 230 V
  • DLS 8D / DLS 4D

    DLS 8D / DLS 4D

    Economical open drawer plan

    • Spacious open drawers with configurable capacity
    • Available in 8 or 4 drawers (DLS4D is add-on version only)
    Drawer heights 8D (8 drawers)
    • 75 mm x 3 drawers
    • 100 mm x 4 drawers
    • 175 mm x 1 drawer
    4D (4 drawers)
    • 75 mm x 1 drawer
    • 153 mm x 2 drawers
    • 175 mm x 1 drawer
    Load weight per drawer Up to 180 kg
    Cabinet dimensions 8D (8 drawers) 915 mm/36"(W) x 610 mm/24"(D) x 1220 mm/46"(H)
    4D (4 drawers) 915 mm/36"(W) x 610 mm/24"(D) x 820 mm/32"(H)
    Electrical supply 100 V - 230 V
  • DLS-V 5D

    DLS-V 5D

    Cabinets dedicated for storing toolholders

    • 5 drawers
    • Storage shelf tray for 6 holders (with HSKA63, C6, 40T connections) or 8 holders (with 30T connections)
    • Maximum of 3 shelf trays per drawer
    • Mountable on DLS4D cabinet
  • TOOLPORT

    TOOLPORT

    Dispenses single inserts and small items

    • Available in 8 or 4 drawers
    Maximum insert capacity 8 drawers 1,600 inserts
    4 drawers 800 inserts
    Cabinet dimensions 8 drawers 676mm x 630mm x 1475mm
    4 drawers 676mm x 630mm x 905mm
    Electrical supply 100 V - 230 V
  • TOOLPORT 4x4 HYBRID

    TOOLPORT 4x4 HYBRID

    Hybrid of TOOLPORT and DLS cabinets

    • Includes 4 TOOLPORT drawers and 4 DLS drawers
    • Ideal for small stocks of tools and supplies
    • Optional touch-screen monitor
  • WIZ

    WIZ

    Ideal for large tools and MRO

    • Reconfigurable with auto-lock doors
    • Available as an add-on cabinet for storing large tools and MRO
    Cabinet dimensions 914 mm/36"(W) x 457 mm/18"(D) x 2070 mm/82"(H)

Options

  • MATRIX ANDROID

    MATRIX ANDROID

    Tool crib management from the palm of your hand

    Dedicated MATRIX Android app manages traditional warehouse and tool room from the palm of your hand!

  • MATRIX POUCH

    MATRIX POUCH

    Always the right tools for the job

    MATRIX Pouch reads Balluff chip on tool adapter. Data string with tool assembly parts is transmitted to MATRIX, allowing quick error-proof access to approved tools

  • MATRIX RTLS

    MATRIX RTLS

    100% visibility anywhere on the shop floor

    MATRIX Real Time Location System tracks production assets that move around on the shop floor. 100% visibility by BLE (Bluetooth low energy) Beacon

Features

  1. Identify the cost drivers
    — MATRIX’s cost analysis and consumption statistics

    Quick overview of transaction history per workpiece, job, employee, and machine helps you identify irregular tool uses and dead stock.

    Find outliers immediately!

  2. Maintain perfect inventory level
    — MATRIX’s automatic purchasing system for optimal ordering process

    Optimal stock levels and re-order points are automatically calculated from previous uses to help you maintain tool availability with minimum inventory. Automatic email alerts make sure you place orders at the perfect time.

    Alert arrives by email

  3. Organize your production floor
    — MATRIX eliminates wasted time looking for tools

    5 minutes spent per day searching for tools will accumulate to 20 hours per year. This is 40 hours per year spent for 2 operators just hunting tools! Eliminate wasted time searching for tools as well as abolish the use of wrong tools for the job with MATRIX.

    Organize with MATRIX
